USB Flash Drive data export with data assurance

What it does

Insert a USB Flash Drive, select memory mode, watch for USB symbol, then push the download (triangular) button.

The instrument memory is dumped onto the USB Flash Drive. The *.csv files are named sequentially, and are not overwritten.

Data typically includes:

1. Source and power meter s/n
2. Test result alpha-numeric name (previously entered by operator)
3. Test result time & date stamp
4. Source nominal power level at each λ
5. Source reference power level at each λ
6. Meter absolute reading level at each λ
7. Meter relative reading level at each λ

Benefit: Simple, reliable & flexible test data recovery

• Gives an instrument endless memory capacity: just dump, empty memory, & continue.
• Back up the day's work, onto multiple Flash Drives if needed.
• Independent of any computing device or operating system; versatile and future-proof.
• Move data files onto a mobile device and send to your office.
  The picture shows a mobile phone's memory card used with a USB adaptor, prior to phoning results back to the office.
• Read data files into KITS™ software for versatile off-site reporting and analysis etc (firmware V1.14 and later). This software alternatively connects to an instrument in real-time if preferred.
• Data files are secure when used with KITS software, which will positively identify if the data file has not been tampered with.
